PFERD 25203701 19 Piece High Speed Steel HSSG Drill Bit Set Metric 1-10mm

Description:

• Full ground drill bits with cross grinding
• 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0, 6.5, 7.0, 7.5, 8.0, 8.5, 9.0, 9.5, 10.0

Features:

• DIN 338 HSSG N STEEL Drill Bit Sets
  • Includes a sturdy plastic box that protects the drills
  • Easy drill selection & storage
  • High speed steel twist drill bits
  • Suitable for general use on steel, cast steel, grey cast iron, annealed cast iron, bronze, brass, aluminium
  • Easy centring, long tool life & good chip removal
• High-performance drilling tools in the STEEL in HSSG (M2) type for industrial uses
• Fully ground, right-hand turning version with cross grinding
• They are precision ground both in the chip flute and the guide chamfer as well as at the drill tip
• They also have cross grinding. These drills are suitable for highly precise positioning on work pieces and support centring during drilling

Recommendations for use:

• Observe the recommended rotational speed
• When drilling metals, use a high-quality cutting oil or cooling lubricant, if possible. This facilitates smooth running and extends the drill tool life. Exception: when working on aluminium, use kerosene instead of cutting oil
• In order to avoid corrosion, remove any particles which develop when working on stainless steel (INOX) from the work piece
• Clean the work piece chemically or mechanically (etching/polishing, etc.).

Specifications:

• Set: 19pc
• Type: Metric HSSG
• Diameter in mm: 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0, 6.5, 7.0, 7.5, 8.0, 8.5, 9.0, 9.5, 10.0

UPC:

• 4007220168172
